Reference Subwoofers 1270

Функции

Reference Subwoofers 1270 SSI™ (Selectable Smart Impedance) - Image

SSI™ (Selectable Smart Impedance)

Stadium subwoofers feature an exclusive dual impedance switch that lets you choose either load impedance option. This allows for a variety of system configurations when using one subwoofer or multiples. Not available from any other manufacturer, SSI lets you reconfigure your system by simply flipping a switch.

Reference Subwoofers 1270 High-roll surround - Image

High-roll surround

Reference woofers incorporate a high-roll surround that provides superior cone edge suspension while maximizing excursion. It not only increases the cone area, it also provides remarkable linear stability and reliability.

Reference Subwoofers 1270 Proprietary cone design - Image

Proprietary cone design

INFINITY subwoofer cones aren’t just built to thump, they’re built to last. Reference woofers feature an exclusive cone design that delivers superior rigidity for long-lasting performance

Reference Subwoofers 1270 Long excursion design - Image

Long excursion design

The longer a subwoofer’s excursion is,the more air it moves. And the more air it moves, the more bass you feel. The long-excursion design in Reference subwoofer ensures big, deep bass output. Just the way you like it.

Технические характеристики и скачанные файлы

Item# INFREFERENCE1270

Описание

Pure Bass Performance.

Reference woofers delivers the enhanced efficiency and higher output. INFINITY uses progressive spiders to provide the best possible control at the excursion limits versus much more commonly used linear spiders. The benefit is a far more controlled woofer stroke with far tighter bass characteristics. With high-roll surrounds, proprietary cone design and long-excursion, Reference woofers deliver deep, powerful bass, with greater accuracy than conventional woofer. And the exclusive SSI™ (Smart Selectable Impedance) switch lets you choose 2- or 4-ohm impedance for maximum configuration flexibility. It’s everything you want in a woofer.

Общее

Description
12" (300mm) car audio subwoofer
Woofer
12" (300mm)
Power Handling
275W RMS, 1100W peak
Sensitivity (@ 2.83V)
93dB
Frequency Response
25Hz – 175Hz
Impedance
2 or 4 ohms, switch-selectable

Размеры

Cutout Diameter
11-1/4" (285mm)
Mounting Depth
6-1/2" (165mm)

Содержимое коробки

  • 1 x Reference 1270
  • 1 x Woofer 12”
  • 1 x Owner’s manual
